Two-side Evaporators Goedhart DVS 62637

VEMAG vacuum stuffer

• Type: ROBOT HP 10C
• Hopper capacity: 250 l
• Productivity: 4000-5000 kg/h
• External dimensions: 2100 x 1350 x 2150 mm
• Filling pressure: max. 40 bar
• Maximum serving size: 0- 10000
• Vacuum pump: 20m3/h
• Total power: 9.5 kW
• Hydraulic pump power: 7.5 kW
• Filling speed adjustable: 0 - 100%

Device for automatic unscrewing and portioning to length

• Type: LPG 208
• Power: 6.0 KW
• External dimensions: 1650 x 1000 x 1350 mm
• For sausages with a caliber of 13 to 40 mm
• For sausages with a length from 20 mm to approx. 400 mm
• Portioning speed: over 2000 ports/min. (depending on the weight of the portion, serving)
• length and housing type used)

VEMAG sausages hanger

• Type: AH 204
• External dimensions: 3250 x 850 x 1700 mm

• Maximum hook feed: 200/min
• Nominal power, total: 1.5 KW

Compressor Bitzer

• Type: S6H-20.2Y
• Volume: 73,6 m3/h
• Cooling capacity for R404A: 32 kW at -25°C/40°C, 20 kW at -40°C/40°C, 13 kW at -50°C/40°C
• Bottle capacity: 73 l
• Dimensions: 1330x1150x1300 mm
• Items in magazine: Sold / Not available
• Condition: Used in good condition



In set with:

Cooler Gea Kuba

• Type: SGKE 50-F61 (x2)
• Cooling capacity for one: 9,3 kW at DT8, 7,5 kW at DT7
• Surface: 39 m2
• Air flow: 6300 m3/h
• Fin spinning: 10 mm
• Electric heaters
• Fans: 1x500 mm
• Dimensions: 1680x800x750 mm
• Refrigerant: Freon
• Volume: 13 l
• Quantity in stock: 2
• Condition: Used in good condition

Refrigerant compressors system Bitzer

• Type: HSK 7451-70-40P (x2)
• Volume: 192 m3/h (x2)
• Cooling capacity for R404A: 344 kW at 0°C/40°C, 284 kW at -5°C/40°C, 230 kW at -10°C/40°C, 149 kW at -20°C/40°C
• Dimensions: 2600 x 1200 x 1700 mm
• Power consumption: 56 kW
• Refrigerant tank and control panel in set
• Items in magazine: Sold / Not available
• Reference number: Z76
• Condition: Used in good condition

Vacuum filler Handtmann

• Type: VF 610
• Hopper capacity: 40 \ 100 (liters)
• Filling capacity: 3000 kg / h
• Stuffing pressure: 35/50 bar
• Porting speed:

    portions size 25 - 450 portions / min
    portions size 50 - 375 servings / min
    portions size 100 - 280 servings / min
    portions size 200 - 190 servings / min

• Power: 3.5 kW
• Weight: 475 kg net
• External dimensions: 120 x 122 x 204 cm
• Condition: After inspection, ready for work
• Number on stock : Sold, not available

The stuffer can work with all popular types of casings: natural casings, collagen

SOLD, not available

1x Compressor set with 3 typical minus screw compressors by Bitzer,

• Compressor type: 3x HSN7471-75-40P
• Volume: 250 m3/h (x2)
• Cooling capacity for R404A: 300 kW at -25°C/40°C, 246 kW at -30°C/40°C, 162 kW at -40°C/40°C
• Oil Separator,
• Refrigerant tank
• Photos in attachments

2x Guntner Freezer Cooler

• Type: S-GHN 081D/312-E
• Cooling capacity: 94 kW at DT8, 75 kW at DT7
• Fin spinning: 12 mm
• Fans: 3 x 800 mm
• Dimensions: 3,650 x 1,400 x 2,000 mm
• Refrigerant: Freon
• Capacity: 154,1 l
• Defrosting: Electric heaters in the tray and on the fans, block defrosted with hot gas,
• Industrial insulated tray
• Industrial industrial design,
• Photos in attachments

• 1x Guntner oil cooler - Photos on request

• 1x Guntner condenser - Photos on request,
