2 stages cooling compressors system Bitzer S6F-30.2Y (x5)

Abele dehairer

• Power: 2.2 kW
• Two-shaft
• With heaters
• External dimensions: 2200 x 960 x 1250 mm
• Working dimensions: 1700 mm
• Power supply: 380V 50Hz 3N
• Made of stainless steel
• Condition: used in good condition
• Stock status : Sold / Not available

Condenser Guntner

• Type: S-GUH 080.1A/1-M(S)-F6-8P
• Number of fans: 1 x 750  mm
• RPM: 800/530
• Dimensions: 2300 x 1110 x 1800 mm
• Entry/exit diameter: 64 / 64 mm
• Quantity in stock: Sold, Not available
• Stock number: SK 155
• Condition: Used in very good condition / fans tested / under nitrogen pressure

Rivacold monoblock refrigeration unit

• Model: FAM 012 Z 001/C
• Power consumption: 1014 W
• Cooling capacity: 1459 W
• The monoblock is suitable for the following applications:

                                   High temperatures: +2°C / +10°C
                                   Medium temperature: -5°C / +5°C
                                   Negative range: -25°C / -15°C

• Dimensions: 800 x 370 x 730 mm
• Weight: 58 kg
• Power supply: 230 V
• Condition: used

Monoblocks are devices that already have a complete common condensing system (condenser)
and heat exchange system (evaporator). This makes it possible to install chambers on roofs without any difficulties
pipe installation. Just connect to the power supply and the unit cools.
